Paradigm Founder Series Center Channel Speaker Color Piano Black (70LC)

Paradigm Founder Series Center Channel Speaker Color Piano Black (70LC)

Name: Paradigm Founder Series Center Channel Speaker Color Piano Black (70LC)
Brand: Center Speakers
Availability: InStock

PARADIGM FOUNDER 70LC PB

Product not available

AL-MAC™ High-Frequency Driver

The Founder’s tweeter is a 1″ (25mm) Aluminum Magnesium Ceramic (AL-MAC™) dome with a proprietary Oblate Spherical Waveguide (OSW™) and a Perforated Phase-Aligning (PPA™) Lens.

AL-MAG™ Midrange Driver

The Founder’s midrange is a 6″ (152mm) Aluminum Magnesium (AL-MAG™) cone with Perforated Phase-Aligning (PPA™) Lens, Advanced SHOCK-MOUNT™ Isolation Mounting System, and a 2” high-temp multi-layered voice coil with ventilated Apical™ former.

Ultra-High-Excursion CARBON-X Unibody Bass Driver

The Founder’s Bass driver is a 6” (152mm), 7” (177mm) or 8” (215mm) Ultra-High-Excursion Unibody CARBON-X™ Cone, over-molded Gen3 Active Ridge Technology (ART™) Surround with Vertical Mounting System, Advanced SHOCK-MOUNT™ Isolation and a 1.5” high-temp multi-layered voice coil with ventilated Apical™ former.

Beautiful Premium-Grade Finishes

Founder Series cabinets are offered in a variety of beautiful premium-grade finishes: Walnut and Black Walnut have a smooth satin finish with distinctive wood figuring. Our exclusive Midnight Cherry and Piano Black feature a luxurious hand-rubbed, high-gloss finish.

ADVANCED Shock-Mount™ System

The Founder Series midrange and bass drivers are mechanically decoupled from the front baffle by our Advanced SHOCK-MOUNT™ Isolation Mounting System. This special mounting hardware uses an elastomer suspension to prevent any transfer of vibration from the driver to the cabinet, and from the cabinet to the driver. By eliminating resonance, the driver is free to render sound purely and efficiently with no audible distortion and maximum clarity.

Dual-Sync™ Continuous Flux Motor

The Founder’s new coaxial midrange driver found on the center channel models, employs OSW™’s oblate spheroid shape with a coaxially mounted tweeter. It maintains detail and sonic focus within the broad and deep sound stage by acting as the waveguide for the tweeter, making its dispersion characteristics ideal for any listening space. Our patented Dual-Sync™ Continuous Flux Motor has taken away the limitations of combined magnet structures as well as having a full-sized, low-distortion and higher output midrange tweeter combination while maintaining a relatively low height for the center channel cabinet, allowing for greater placement flexibility.

Cascade-Fusion Bracing

Cascade-Fusion Bracing inside Founder Series’ faceted cabinets increase rigidity and break up standing low-frequency waves. This delivers much tighter bass with greater clarity and accuracy. All bracing is extensively reinforced, making the cabinet into a monolith stronger than the sum of its parts. The inherent strength of the geometric cabinet profile distributes the load points across a larger cabinet area providing greater support and rigidity than can be achieved with traditional square cabinet geometry.

Proudly Crafted in Canada

The Founder Series is completely designed, engineered, and built at our state-of-the-art manufacturing facility just outside of Toronto, Canada. It’s made by people who love great audio (just like you). From the hand-chosen, specially engineered components and materials, to the precise workmanship of the non-resonant cabinets with their beautiful premium-grade finishes, Founder Series is truly hand-built for performance. Sure, we could say “Made in Canada,” or “Manufactured in Canada.” But we believe that building loudspeakers is an art. Everyone at Paradigm shares a passion for crafting speakers, and it’s from this intense passion that “Crafted in Canada” was proudly born.

Partnered with the NRC

Paradigm is partnered with Canada’s world-renowned NRC in ongoing research to reveal the true nature of sound and human hearing. Findings influence design and performance specs, resulting in a uniquely realistic listening experience, backed by sound science.

DIMENSIONS

Height : 8 inches / 20.4 cm

Width : 18.9 inches / 48 cm

Depth : 12.3 inches / 31.3 cm

Weight : 30 lbs / 13.6 kg each

GENERAL

Surface Finish : Piano Black

Design : 4-driver, 3 way LCR, sealed enclosure

Crossover : 2nd order electro-acoustic at 2.2 kHz (tweeter), 2nd order @ 700 Hz (bass)

Frequency Response : ◊ ON-AXIS : ±2dB from 79 Hz - 23 kHz ◊ 30° OFF-AXIS : ±2dB from 79 Hz - 17 kHz

High Frequency Drivers : Coaxial 1" (25mm) AL-MAC™ Ceramic Dome with Oblate Spheroid Waveguide (OSW™) and Perforated Phase-Aligning (PPA™) Tweeter Lens, ferro-fluid damped / cooled, Patent Pending Dual Gap Motor Structure

Mid Frequency Drivers : Coaxial 6” (152mm) AL-MAG™ Cone with SHOCK-MOUNT™ Isolation Mounting System, a 2” high-temp multi-layered voice coil with Apical™ former, Patented Dual-Sync™ Continuous Flux Motor

Low Frequency Drivers : Two 5.5" (127mm Ultra-HighExcursion CARBON-X™ Unibody Cone, Gen3 Active Ridge Technology (ART™), and a 1.5” high-temp multi-layered voice coil with ventilated Apical™ former

Low Frequency Extension : 47 Hz (DIN)

Sensitivity : 92 dB

Anechoic : 89 dB

Power Amplifier(s) : 15 - 220 watts

Maximum Input Power : 150 watts

Impedance : Compatible with 8 ohms
