Arcam AVR31: Home Theater Receiver w/ Dolby Atmos

ACCESSORIES

Included : Mains lead, Remote control with 2 x AAA batteries, Quick Start Guide (full manual online), DAB/FM aerial, 3 x Wi-Fi/Bluetooth antennas, Calibration microphone, USB cable.

DIMENSIONS

Width : 433 mm / 17.1 inch(es)

Depth : 425 mm / 16.7 inch(es)

Height : 171 mm / 6.7 inch(es)

Weight : 18.1 kg / 39.9 lb(s)

GENERAL

Power Supply Voltage : 110–120V or 220–240V, 50–60Hz

Power Consumption : Max : 1.5kW ◊ Typical : 100W

Standby Consumption : <0.5W

Maximum Input : 4.5V rms

Sensitivity : 1V, 2V, 4V (user adjustable)

Input Impedance(s) : 47kΩ

Signal to noise ratio : 100dB/110dB

Frequency Response : 20Hz—20kHz ± 0.2dB

Power Output : 2 channels driven, 20Hz - 20kHz, <0.02% THD : 120W/200W ◊ 2 channels driven, 1kHz, 0.2% THD : 140W/220W ◊ 7 channels driven, 1kHz, 0.2% THD : 100W/180W

Noise : <0.15mV

Features : • 16 Channels of Dolby Atmos, DTS:X & AURO-3D decoding • 7 HDMI inputs, 3 HDMI outputs inc Zone 2, eARC compatible • HDMI 2.1 with HDCP2.3 • All inputs support 8K@60fps and 4K@120fps • Supports Dolby Vision, HDR10+, HDR10 and HLG • Includes Dirac Live® room correction • Ready for Dirac Live Bass Control* • Dual ESS 9026PRO audiophile DACs with ESS reference voltage regulators • 7 Channels of high power Class G amplification • Wi-Fi / Ethernet, RS232 and IR control • Google Chromecast® built-in for streaming audio • Apple® Airplay2 • Bluetooth aptX®HD • Free MusicLife iOS and Android UPnP app • Supports MQA • Roon Ready

HEADPHONE SECTION

Maximum Output : 5Vrms into 32Ω

Output Impedance(s) : <100Ω

PACKAGING DIMENSIONS

Weight : 21.4 kg / 47.2 lb(s)

PREAMPLIFIER SECTION

Nominal Output Level : 1V RMS (max. 5V RMS)

Output Impedance(s) : 560Ω

THD + N : –100dB (20Hz—20kHz)

UPC

UPC : 050667378967
