Cambridge Audio AXR100 Stereo Receiver

DIMENSIONS

Width : 110 mm / 13.4 in

Height : 430 mm / 16.9 in

Depth : 340 mm / 13.4 in

Weight : 8.1kg / 17.8 lb(s)

GENERAL

Power Output : 100 watts (into 8Ω)

Thd (Unweighted) : <0.01% @ 1kHz, 80% of rated power <0.15% 20Hz - 20kHz, 80% of rated power

Frequency Response (-1db) : 5Hz - 50kHz

S/n Ratio (Ref 1w) : >82dB (unweighted)

Input Impedance(s) : 47k ohms

Power Amp Damping Factor : >50

Standby Power Consumption : <0.5W

Power Consumption (Max) : 550W

Bass/treble Controls : Shelving, ultimate boost/cut +/- 10dB @ 100Hz and 20kHz

Subwoofer Output : 200Hz 2nd order L+R Level follows volume setting

Optical Digital Inputs : PCM 16-24-bit S/P DIF Co-axial 32-192kHz TOSlink Optical 32-192kHz

Bluetooth™ : 5.0 A2DP/AVRCP supporting SBC

Tuner Bands : European AM (522-1629kHz) FM (87.5-108MHz) / US AM (530-1710kHz) FM (87.5-108MHz)

Aerial Inputs : FM 75 ohms, Coaxial. AM 300 ohms wire loop/ single wire

Signal To Noise : 60dB typical (FM)

Distortion (Tuner) : <0.4% @ 1kHz 50kHz deviation (FM mono) <0.6% @ 1kHz 50kHz deviation (FM stereo)

UPC

UPC : 813371029552

WHAT'S IN THE BOX

Included : AXR100 Stereo Receiver, Power Cable, Remote Control, 2 x AAA Batteries
